Tools and machines
It is of great importance to us that our machines operate economically, technically and qualitatively at a high level. Our machines operate for your success, and your success is our business.
Modern industries require flexible, modular and user-oriented machinery. Starting from your demands we plan the production process of your product based on the latest findings in the field.
TMK Zerspanungstechnik uses modern machines, CAD/CAM and advanced measuring techniques. This puts our company into position to create highly complex products from technical plastics precisely and always on schedule.
Our employees are trained regularly in the latest CNC-technology to make sure that our machines are operated to their maximum potential.
CNC UNIVERSAL MILLING MACHINE SPINNER TC600-85 SMCY
Stroke: X 275 / Y(+50/-40) / Z 700 mm
Control: SIEMENS
CNC UNIVERSAL MILLING MACHINE Spinner VC 750 XL
Stroke: 460 x 460 x 950 mm
Hopper: 32 x
Control: 840DE-SolutionLine
CNC UNIVERSAL MILLING MACHINE SPINNER Spinner VC 750
Stroke: 460 x 460 x 760 mm
Hopper: 32 x
Control Siemens 840 D-SL
CNC Universal Milling machine Spinner VC650
Travel range: 500 x 500 x 600 mm
Hopper: 24 x
CNC Universal Milling machine Spinner VC360 XL
Travel range: 300 x 300 x 560 MM
Hopper: 24 x
CNC Universal Turning machine Spinner tc82mc
Mandrel opening: 82 mm
Max. width: 1000 mm
Turret: 12 x; moving tools; VDI 50
CNC Universal Milling machine Spinner U5 1520
Travel range: 160 x 520 x 1520 mm
Hopper: 24-fach High Speed
Turning machine Ergomat tbc60
Gang-type CNC universal automatic lathe TNG 42
Bar capacity: 42 (1 5/8”)mm (inch)
Chuck ø: 135 (5″) mm (inch)
Turning ø over cross slide: 70 (2 3/4″) mm (inch)
CNC MILLING MACHINE SPINNER TC 77 SMCY
Maximum turning diameter 500 mm
Strand passage 77
12 compartment turret VDI 50
counter spindle
Samsys-Smart bar feeder 63
Diameter: 5 – 65 mm
Bar length: max. 1200 mm
Loading capacity: 650 mm, Ø 65 mm x 10 Stk.
Loading Cycle: ca. 8 Sek.
CNC Universal Turning machine Spinner TC-108
Maximum turning diameter 420 mm
Bar passage 107 mm
12 compartment revolver VDI 40
MILLING MACHINE SPINNER MVC1100-A / MODEL 2007
Travel range: 500 x 600 x 1100 mm
Hopper: 24 x
List of machinery:
CNC UNIVERSAL MILLING MACHINE SPINNER TC600-85 SMCY
Stroke: X 275 / Y(+50/-40) / Z 700 mm
CNC UNIVERSAL MILLING MACHINE SPINNER VC 750 XL
Stroke: 460 x 460 x 950 mm
Hopper: 32 x
CNC UNIVERSAL MILLING MACHINE SPINNER SPINNER VC 750
Stroke: 460 x 460 x 760 mm
Hopper: 32 x
CNC UNIVERSAL MILLING MACHINE SPINNER VC650
Travel range: 500 x 500 x 600 mm
Hopper: 24 x
CNC UNIVERSAL MILLING MACHINE SPINNER VC360 XL
Travel range: 300 x 300 x 560 mm
Hopper: 24 x
CNC UNIVERSAL TURNING MACHINE SPINNER TC82MC
Mandrel opening: 82 mm
Max. width: 1000 mm
Milling machine Spinner U5 1520 / Model 2015
Travel range: 160 x 520 x 1520 mm
Hopper: 24-fach High Speed
Milling machine Spinner MVC1100-A / Model 2007
Travel range: 500 x 600 x 1100 mm
Hopper: 24 x
Milling machine Spinner VC 650 / Model 2004
Travel range: 500 x 500 x 600 mm
Hopper: 24 x
Milling machine Spinner VC 360 XL / Model 2009
Travel range: 300 x 300 x 560 MM
Hopper: 24 x
Milling machine Maho-600 E
Travel range: 400 x 500 x 500 mm
Equipment: Swing table
Turning machine Spinner TC108 MC / Model 2004
Mandrel opening: 110 mm
Max. width: 1000 mm
Turret: 12 x; moving tools; VDI 50
Turning machine Spinner TC82 / Model 2001
Mandrel opening: 82 mm
Max. width: 1000 mm
Turret: 12 x; moving tools; VDI 50
Turning machine Spinner TC77 SMCY / Model 2006
Mandrel opening: 77 mm
Max. width: 1000 mm
Turret: 12 x; moving tools; VDI 50
Arbor Y-Axis; Main and counter spindle with C-axis
Turning machine Ergomat TBC 60 / Model 2005
Mandrel opening: 60 mm
Tool carriage: 3
Turret: 8 x; moving tools; VDI 30
Rear side: 3 tools
Bar loader: 1200 mm
Lathe Bulmak conventional / Model 2000
Max. width: 1000 mm
Max. diameter: 350 mm
Diverse plastics treatment machines
- CNC full sawing machine Bauer
- Format saw Format 4
- Planer Martin
- Table milling machine SCM
- Band saw Bauer
- Sawing machine Bauer
- Div. pillar drilling machines
